RS-AP01 Industrial Tablet

2.45GHz Active RFID

Frequency

2.40~2.48GHz

Sensitivity

-90dBm

Output Power

Max + 15aBm (Software adjustment 2dBm)

Reading Range

0-80m (depend on the tag power output)

Identification speed

150/s

Anti-collision

150 tags reading simultaneously

Application Software

Platform

Provide development kit of API

Performance

CPU

Octa-core, 2.0GHz; GMS&AER

RAM+ROM

4GB + 64GB

Expansion

Supports up to 256 GB Micro SD card

Operating System

Android 13

Communication

WLAN

Support 802.11 a/b/g/n/ac/d/e/h/i/k/r/v, 2.4G/5G dual-band, IPV4, IPV6;

Fast roaming: PMKID caching, 802.11r, OKC;

Operating Channels: 2.4G (channel 1~13), 5G(channel 36,40,44,48,52,56,60,64,100,104,108,112,116,120,124,128, 132,136,140,144,149,153,157,161,165),Depends on local regulations;

Security and Encryption: WEP,WPA/WPA2-PSK(TKIP and AES),WAPIPSK—EAP-TTLS,EAP-TLS, PEAP-MSCHAPv2, PEAP-LTS, PEAPGTC, etc.

WWAN

4G: TDD-LTE: B34/B38/B39/B40/B41       FDD-LTE: B1/B2/B3/B4/B5/B7/B8/B12/B13/B17/B20/B28

Bluetooth

Bluetooth 5.1

Vo-LTE

Support Vo-LTE HD video voice call

GNSS

GPS/AGPS, GLONASS, BeiDou, Galileo, internal antenna

Physical Characteristics

Dimensions

250.8 x 152.0 x 15.0 mm (for standard version)

Dimension

700g

Display

8” IPS LTPS 1920 x 1200

Touch Panel

Corning Gorilla Glass, multi-touch panel, gloves and wet hands supported

Power

Main battery: Li-ion, rechargeable, 8700mAh

Standby: over 500 hours

Continuous use: over 10 hours ( depending on user environment )

Charging time: 5-7 hours ( with standard AC adaptor and USB cable )

Expansion Slot

1 slot for Micro SIM card, 1 slot for Micro SIM / TF card, Optional dual PSAM card slots

Interfaces

USB 2.0 Type-C, OTG

Audio

Speaker, microphones

Keypad

1 front key , 1 volume key , 1 power key , direction key (optional)

Sensors

Gravity sensor; gyroscope; geomagnetic sensor; light / proximity sensor

Barcode Scanning (optional)

Scan engine

Zebra SE4710; Honeywell HS7

2D Symbologies

PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch, Postal (KIX), etc.

Camera

Camera

13 MP Autofocus with flash

Front Camera

5 MP

User Environment

Operating Temp.

-20 °C to 50 °C

Storage Temp.

-40 °C to 70 °C

Humidity

5% RH – 95% RH non condensing

Drop Specification

Multiple 1.5 m / 4.9 ft. drops to the concrete across the operating temperature range

Tumble Specification

500 x 0.5 m / 1.64 ft. falls at room temperature

Sealing

IP65 per IEC sealing specifications

ESD

±15 KV air discharge, ±8 KV conductive discharge

NFC

Frequency

13.56 MHz

Protocol

ISO14443A/B, ISO15693, NFC-IP1, NFC-IP2, etc

Chips

M1 card (S50, S70), CPU card, NFC tags, etc.

Range

0-4 cm

Chips

M1 card (S50, $70), CPU card, NFC tags, etc.

Range

2-4 cm

Barcode Scanning (Optional)

1D Linear Scanner

Honeywell: N4313

1D Symbologies

UPC/EAN, Code128, Code39, Code93, Code1Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5,Codabar. MSl, RSS,etc.

2D Imager Scanner

Zebra: SE4710 /SE4750SR/ SE4750MR/SE4750DP
Honeywell: N6603; CM60

2D Symbologies

PDF417, MicroPDF417, Composite, RSS, TLC-39,Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet, US Planet, UK Postal, Australian Po
